Water Curtain Sprinklers - Closed - type Water Curtain Sprinklers Introducing our Water Curtain Sprinklers - Closed - type Water Curtain Sprinklers (Window Sprinklers), a crucial part of the water - curtain system from Chuan'an Fire Protection. These sprinklers are designed for fire...
Description
Ca-Fire Protection Co.,Ltd is one of the most credible manufacturers and suppliers of ca-fire water curtain sprinkler head water curtain nozzle in China. Welcome to wholesale custom made fire equipment products at competitive price from our factory. Contact us for more cheap products.
Water Curtain Sprinklers - Closed - type Water Curtain Sprinklers
Introducing our Water Curtain Sprinklers - Closed - type Water Curtain Sprinklers (Window Sprinklers), a crucial part of the water - curtain system from Chuan'an Fire Protection.
These sprinklers are designed for fire separation and protective cooling. They work perfectly with fire - proof curtains, fire - proof rolling shutters, doors, windows, and glass curtains. Ideal for installation at windows, sill openings, protective walls, and for protecting internal fire - proof rolling shutters in buildings.
Product Models and Features
We offer a variety of models to meet different needs:
ZSTMA - T and ZSTMB - T Series: With different connection threads and structural designs, they ensure reliable performance in fire - protection scenarios.
ZSTMB - T80/170 - 68°C: Specially engineered to respond quickly at 68°C, providing timely fire - fighting support.
Technical Parameters
| Specification Model | Installation Method | Connection Thread | Flow Characteristic | Spray Angle | Minimum Working Pressure (MPa) |
|---|---|---|---|---|---|
| ZSTMz (Combined Water Curtain) | Upright | R1 or welded | 15 - 200 | 120° | 0.35 |
| ZSTMA - T10/150 | Hanging | R1/2 | 10 | 150° | 0.1 |
| ZSTMA - T21.5/150 | Hanging | 21.5 | |||
| ZSTMB - T8/120 | Hanging or Horizontal | 8 | 120° | ||
| ZSTMB - T18/120 | 18 | ||||
| ZSTMB - T28/120 | 28 | ||||
| ZSTMB - T35/120 | R3/4 | 35 | |||
| ZSTMB - T50/120 | 50 | ||||
| ZSTMB - T80/170 - 68°C | R1/2 | 80 | 170° |
Choose our Water Curtain Sprinklers for a strong and reliable fire - protection solution. Protect your property and ensure safety with Chuan'an Fire Protection's quality products.
