Dry Sprinkler Freeze Safe Fire Suppression for Unheated Warehouses
Freeze-proof dry pendent sprinkler, brass body, –40 °C rated, instant flow in cold warehouses, garages, offshore platforms—no heat tracing, no burst pipes, reliable NFPA-compliant fire suppression.
Description
Ca-Fire Protection Co.,Ltd is one of the most credible manufacturers and suppliers of dry sprinkler freeze safe fire suppression for unheated warehouses in China. Welcome to wholesale custom made fire equipment products at competitive price from our factory. Contact us for more cheap products.
Products Description
CA-FIRE Dry Sprinkler
Engineered for dry-pipe and pre-action sprinkler systems in sub-zero environments, our Dry-Type Pendent Sprinkler eliminates freeze-damage risk by relocating the precision German K-factor glass bulb and metal seal to the top of the threaded inlet, leaving the entire drop nipple empty of water. With no trapped water or condensate to expand on freezing, this freeze-proof sprinkler is the go-to solution for unheated warehouses, cold-storage logistics, parking decks, and seasonal facilities that must be fully drained between cycles, delivering reliable, maintenance-free fire suppression down to –40 °C without costly heat tracing.
Working Principle
Inside the dry pendent sprinkler, incoming air pressure does two jobs at once. Most of the compressed air sits above the clapper valve, holding back the water supply; a small, carefully-metered drop in pressure-triggered by heat-bulb activation-peels off and releases the clapper. That sudden loss of pressure lets the valve swing open, allowing water to surge through the previously empty drop nipple and out the deflector. The water meets open air, atomizes, and forms a uniform spray that blankets combustibles and knocks down the fire-no trapped water, no freeze damage, no fuss.
Products Features
Wide Operating Range
Freeze-proof dry pendent sprinkler handles flow rates from 15–150 gpm and pressures 0.2–1.2 MPa with minimal pressure loss, fitting everything from small cold-storage rooms to high-hazard flammable-liquid zones.
01
Enhanced Safety
Integrated air-monitoring valve, redundant pressure gauge, and heat-responsive German glass bulb ensure reliable dry-pipe activation and eliminate water-column freeze bursts in sub-zero environments.
02
Flexible Installation
Horizontal sidewall or vertical pendent mounting in ½", ¾" and 1" NPT/BSP threads allows single-tool retrofits in tight ceiling spaces, unheated warehouses, parking decks and offshore modules.
03
Durable Build
Brass body with chrome-plated deflector and EPDM O-rings rated –40 °C to +120 °C delivers 30-year corrosion resistance and 100 000-cycle functional endurance without seasonal maintenance.
04
Technical Parameter
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Application Industries & Scenarios
Dry-pendent sprinklers turn freeze-risk zones into fully protected fire-safe spaces. In unheated warehouses, they eliminate burst-pipe downtime and keep stored goods dry until a real fire triggers water flow, cutting insurance premiums and replacement costs. Cold-storage and blast-freezer facilities gain continuous fire suppression without heat tracing, saving up to 30 % on energy bills while preventing ice blockage that could paralyze an entire supply chain. Parking garages and loading docks benefit from corrosion-resistant brass construction that withstands road salt and vehicle exhaust, delivering instant suppression without false alarms from condensation. Data centers using free-air cooling rely on the dry valve to avoid water near servers, yet enjoy full NFPA-compliant coverage for lithium-ion battery rooms. Heritage archives and museums protect irreplaceable collections from accidental water damage while meeting strict preservation climates. Offshore wind platforms, mining shafts, and remote chemical terminals count on the system's –40 °C rating for year-round readiness where any freeze means costly helicopter call-outs. From rooftop penthouses to sub-zero logistics hubs, dry-pendent sprinklers provide freeze-proof, energy-saving fire suppression that keeps operations, assets, and people safe 24/7.
